EBS Boltmark II · Continuous inkjet (CIJ)
EBS-6900
Continuous inkjet coding for fast lines, with the full option set.
A single-head continuous inkjet printer for production lines that run all day. It marks dates, batch numbers and codes on almost any surface without touching the product, and every option in the Boltmark II range can be fitted to it.
Request a quoteThe EBS-6900 is the fully-equipped model in the Boltmark II series. Where the EBS-6600 covers simple, single-line coding, the 6900 is built for lines that need more print area, more stored messages and networked control.
It draws 19 W, needs no compressed air, and weighs 12.5 kg dry, so it can be moved between lines on a wheeled stand rather than dedicated to one machine. The integrated ink system is replaced in three steps without tools, which means a line operator can do it instead of waiting for a technician.
For plants where a power cut means a blocked nozzle and a lost shift, the anti-clogging power supply keeps the printer running through interruptions under 30 seconds and performs a controlled rinse and shutdown beyond that.
Configurations
- MIDIStandard25 dots3 lines
- MAXI32 dots4-5 linesOptional build. Adds the 32x18 print matrix.
Factory options
- Angular 90° printhead
- 6 m printhead cable
- IP65 protection class
- Heavy-duty printhead hose for harsh conditions
- Food option, for use with food-grade inks
- Robot option for print direction change
- my.ebs.ink server for remote operation
- Anti-clogging power supply
- Message memory extended to 2000
- Arabic or Cyrillic keypad layout
Accessories
- Photocell / product sensor
- Shaft encoder
- Printhead holder
- Pistol grip printhead holder
- Manually operated sliding table
- External status alarm light
- Printer stand, with or without wheels
Marks on
Used in
Documents
Related printers
Request a quote
Send the configuration and we will come back with a price and lead time.
